APC 2000 ALW/L Hydrostatic Level
Measuring range : From 200 Up to 3000 mmH2O
(Up to 20m APC - 2000 ALW/L)
Output Signal : 4 - 20 mA + HART
Intrinsic safety and explosion proof certificates
Accuracy : 0.16 %
Version with Local display
NES - Conductive Level
Contact: 5 contacts via relay
Connection : G ½, G 1½ male Theard
Material: stanless-steel
Hastelloy®,titanium
Pmax: 30 bar
Tmax:150°C
For conductive liquids (>20 μS/cm)
NMT -Magnetostrictive Level Meters
Measuring length: 300 - 4000 mm
Connection: G 2, 2" NPT male thread
Material: stainless steel
pmax: PN10
tmax: 70°C
Accuracy: ±1 mm
Output: 4 - 20 mA
JUMO NESOS R03 LS
Density: 700 to 1400 kg/m3
Temperature: --30 to +150 °C
Pressure range: -1 to +6 bar
ERH- Level switch
Explosion proof version
Housing protection IP66/68
pressure 40bar
Marine certificates (DNV-GL, LR, BV, PRS)
APLISENS SGE-25 Hydrostatic Level
Measurnig range:
From1 up to 500 mh2O
Output signal: 4….20 mA
Accuracy: 0,2%
Material: Hastelloy/316Lss diaphram
Marine certificate DNV GL
MM-Float Transducer-Reed Chain
Measuring length: max. 6 m
Connection: R ⅜ ... R 2, DIN-flange DN40 ... DN125, ASME 1½" ... 4"
Material: stainless steel, PVC, PPH, PTFE
pmax: 30 bar
tmax: 130°C
Accuracy: 0.5 % for L = 2 m
