Flow

Other Flowmeters

 Switching range: 300 - 3600 m
Connection:&nbsp;G&nbsp;⅜&nbsp;,G 2,&nbsp;⅜&nbsp;<br />
, flange DN10 ... DN50,<br />
weld-on flange DN40 ... DN500<br />
<i class="fas fa-check-circle"></i>Material:&nbsp;brass, stainless steel, PVC<br />
pmax:&nbsp;PN16<br />
tmax:&nbsp;100&deg;C<br />
<i class="fas fa-check-circle"></i>Accuracy:&nbsp;&plusmn;3 ... &plusmn;5 % of full scale</p>

• linig material
•  Switching range: 300 - 3600 m

Air/Gas/Steam Flowmeters

Pipe diameter range 25 mm to 1500 mm
Temperature range for sensors -20 °C to +135 °C
Protection Type: IP 66
Pressure Max:  range1 bar
Flow velocities: 0.1 m/s to 75 m/s

ANU Pitot Tube – Differential Pressure

Measuring Range:
7 - 3440 Nm³/h air max. 224 Nm/s
Accuracy: ±1,5 % of reading
pmax: 100 bar
tmax: 180°C
Connection: G ½ ... G 2 male; ½" ... 2" NPT male
Material: Sensor- st-steel 1.4571, glass

KEC – Thermal Energy Flow meter

Measuring Range:
7 - 3440 Nm³/h air max. 224 Nm/s
Accuracy: ±1,5 % of reading
pmax: 100 bar
tmax: 180°C
Connection: G ½ ... G 2 male; ½" ... 2" NPT male
Material: Sensor- st-steel 1.4571, glass

DVH- Vortex Flow Meter

Measuring range:
3 - 28 ... 549 - 9034 Nm³/h
(20°C, 0 bar rel) air
Connection: ANSI ½ ... 8",
flange DN15 ... DN200, wafer flange
Material: stainless steel, Hastelloy
pmax: PN 16, 40, 100
tmax: 260°C (400°C)
Accuracy:
±1 % of reading gas/vapour

PEM-1000

Process connection flange DIN, ANSI
Protection Type: IP67
Accuracy: 0,5%
Pressure rating: PN16
Lining: Rubber or PTFE

JUMO flowTRANS MAG I02

Measuring range: 0.2 to 10 m/s
Temperature max: 110 °C
Pressure: PN 16
Input / Output: 4 to 20 mA; pulse frequency;
2 x switching output (relay); digital input

JUMO flowTRANS MAG H10

connection: Screw connection; welded socket; Tri-Clamp; flange; external thread
accuracy: 0.5 % of the measured value
Lining materials: PFA
Electrode material: Stainless steel
Temperature range: 130 °C
Pressure: PN 10 to PN 40
Output: Analog output 4 to 20 mA; digital output 1 and 2 (passive)

        EPS-FlowMeter

Measuring range: 0.05 ... 40,715 m³/h
Connection: flange DN10 ... DN1200
, ANSI ½ ... 48"
Lining material: hard rubber
pmax: PN40
Temperature range: -20 ... +150°C
Accuracy: ±0.3 %
Output: analogue/ pulse output

MIM-Magnetic Inductive FlowMeter

Measuring range: 0.6 - 160 m³/h ... 1 - 250 m³/h liquids
Accuracy: ± 0.5 %
pmax: 16 bar
tmax: +70 °C
Connection: flange
Material:steel, paint coated (process connection),NBR, (lining) Hastelloy®,(electrodes)
Output: 2x analogue,
Input: 1x control inpu

MIS- Magnetic Inductive FlowMeter

Measuring range: 0.6 - 160 m³/h ... 1 - 250 m³/h liquids
Accuracy: ± 0.5 %
pmax: 16 bar
tmax: +70 °C
Connection: flange
Material:steel, paint coated (process connection),NBR, (lining)
Hastelloy®,(electrodes)
Output: 2x analogue,
Input: 1x control input

JUMO flowTRANS US W01

Housing: Metal-free plastic

Connection: from DN 15 to DN 32

Accuracy: 2 % of the measured value

tmax: 70 °C
pmax: PN 16

Measuring Range: 1:100 (0.1 to 10 m/s)

Materials: in contact with the medium

PPSU, PEEK, EPD
